2.3M JAS39
$150.00
We wanted this one to go above and beyond as a beautiful scale model. We found ways to make it reliable and tough enough to actually be flown on a regular basis, and not a problem to transport or put together, all in a package that fly’s brilliantly well.
Description
SPECIFICATIONS:
Model: 2.3M jas39
Wingspan:1370 mm
Length:2340 mm
Weight: 13-14kg
BASIC SETUP:
Control throws:
Aileron: 15 degrees up / 15 degrees down – 50% Expo
Rudder: 30 degrees left / 30 degrees right – 35% Expo
Elevator: 20 degrees / 20 degrees – 35% Expo
The CG is 190mm from the front leading edge on the root of the wing
FEATURES:
Full composite construction, lightweight and strong
INCLUDED HARDWARE:
Complete air frame (including fibreglass control horns)
Carbon fibre wing-tubes
Servo extension leads
Fixed Dual wall thrust pipe (for 120-160N turbines)
Fuel tank (3500ml
REQUIRED HARDWARE:
Turbine: 120-160N
Servos: x12
x9 middle size servo,12-20kg
x3 standard size servo, 30-40kg
Also requires all the usual accessories such as transmitter, receiver, batteries, powerbox and possibly other small accessories.
Additional information
| Size | 32, 34, 36, 38 |
|---|
